Equipment> Tire Changers

All Tire Changers come with a step by step instruction manual.

Click on images to enlarge.




Atlas TC229 Tire Changer - $2,250.00

The Atlas® 229 wheel clamp tire changer is the perfect tire changer for the small automotive garage or ATV/MC dealer. The Atlas® 229 has the same clamping and tire changing capabilities as the Atlas® TC 221 wheel clamp tire changer, but has the added bead blaster system to help inflate stiff sidewall tires or other "hard to inflate" tires. If you are going to be changing larger pickup truck (1 ton), large SUV wheels, or agricultural tires (either now or in the future), you may want to consider the Atlas® 289 wheel clamp tire changer.

  • Tire Inflator
  • 3 Positions For Clamping Jaws
  • Oiler, Filter, Regulator included
  • 90-110 Psi
  • Beadblaster
  • 110v
  • Inner Clamp 11 5/8” – 25 1/4”
  • Outer Clamp 9 3/4”- 23 1/4”
  • Max Tire Diameter: 39”
  • Max Wheel Width: 13”

Atlas® TC229 Specifications

Rims Steel, Aluminum, Alloy
External Locking Rim Dimension 9 3/4" - 21 5/8"
10 3/4" - 22 1/2"
11 5/8" - 23 1/4"
Internal Locking Rim Dimension 11 5/8" - 23 1/4"
12 5/8" - 24 1/4"
13 1/2" - 25 1/4"
External Locking Rim Dimension
(With Flip Adapters
In The ATV Configuration)
Position 1) 2 7/8" - 14 3/4"
Position 2) 3 3/4" - 15 5/8"
Position 3) 4 5/8" - 16 5/8"
External Locking Rim Dimension
(With Flip Adapters In The
Motorcycle Configuration)
Position 1) 12 5/8" - 24 1/2"
Position 2) 13 5/8" - 25 1/2"
Position 3) 14 1/2" - 26 3/8"
Bead Blaster Yes
Maximum tire diameter 39"
Operating voltage 110V 1Ph
Maximum wheel width (Bead Breaker) 13"
Air pressure 90 - 110 psi
Maximum Inlet Pressure not to exceed 140 PSI*
Shipping weight 500 LB.
Turntable Rotating Torque 885 ft/lbs.
Wheel clamping 4 jaws: internal/external
Bead breaker Pneumatic, 5,500 LB. force
Oiler, filter, regulator Included
Soap reservoir Included
Warranty 1 yr. limited
4 Black plastic rim protectors Included
*Inlet pressure is the amount of air pressure that your air compressor is supplying.



Atlas TC289 Tire Changer - $2,550.00

The Atlas® TC 289 wheel clamp tire changer is the perfect wheel clamp tire changer for most general automotive service departments and medium sized tire stores. This tire changer is perfect for changing the tires on large SUV and one ton trucks. The Atlas® TC289 can be fitted with the LH assist arm, RH assist arm, or Atlas® DAA arm assembly.

The Atlas® wheel clamp tire changers are designed to change the tires on both high priced alloy wheels and steel wheels without damaging the rim or the tire. The powerful ADJUSTABLE bead breaker located on the side of the tire changer is designed to break even the most stubborn and rusted beads without damage to the rim. The turntable jaws (which can be covered with the standard protective plastic inserts) hold the rim securely without damaging the surface of the rim. These jaws can be moved to three different positions along the slides of the turntable to either increase or decrease the clamping range of the Atlas® TC289 wheel clamp tire changer.

The Atlas® TC 289 wheel clamp tire changer comes standard with the powerful bead blast system and inflator hose adapter and pressure gauge.

  • Tire Inflator
  • Adjustable Bead Breaker
  • 3 Positions For Clamping Jaws
  • Oiler, Filter, Regulator included
  • 90-110 Psi
  • Beadblaster
  • 110v
  • Inner Clamp: 14” - 30”
  • Outer Clamp: 12”- 28”
  • Max Tire Diameter: 47.5”
  • Max Wheel Width: 18.5”

Atlas® TC289 Specifications

Rims Steel, Aluminum, Alloy
External Clamping Range Position 1) 11 7/8" - 26"
Position 2) 12 7/8" - 27"
Position 3) 13 3/4" - 28"
Internal Clamping Range Position 1) 13 7/8" - 27 7/8"
Position 2) 14 5/8" - 28 7/8"
Position 3) 15 5/8" - 29 7/8"
External Locking Rim Dimension
(With Flip Adapters In The ATV Configuration)
Position 1) 5" - 19 1/8"
Position 2) 5 7/8" - 20 1/8"
Position 3) 6 7/8" - 21 1/8"
External Locking Rim Dimension
(With Flip Adapters In The
Motorcycle Configuration)
Position 1) 15" - 29 1/8"
Position 2) 15 7/8" - 30"
Position 3) 16 7/8" - 31"
Bead Blaster Yes
Maximum tire diameter 47 ˝"
Operating voltage 110V 1Ph
Maximum wheel width (Bead Breaker) Position 1) 14 ľ"
Position 2) 18 ˝
Air pressure 90 - 110 psi
Maximum Inlet Pressure not to exceed 170 PSI*
Shipping weight 618 LBS.
Turntable Rotating Torque 885 ft/lbs.
Wheel clamping 4 jaws: internal/external
Bead breaker Pneumatic, 5,500 LB. force
Oiler, filter, regulator Included
Soap reservoir Included
Warranty 1 yr. limited
4 Black plastic rim protectors Included
*Inlet pressure is the amount of air pressure that your air compressor is supplying.
