All lifts come with a step by step instruction manual. Delivery and installation charges are extra please call for pricing.


Atlas Cycle Lift XLT - $1,650.00 (Click image to enlarge)

HT-CYCLELIFT-fslash-HT-CYCLELIFT-EXT-2.jpg (36181 bytes)The Atlas® Cycle Lift XLT ATV and golf cart air operated lift is the Atlas® Cycle Lift that has been equipped with the Atlas® Cycle Lift XLT kit. The Atlas® Cycle Lift XLT kit consists of two removable 93" X 12" diamond plated side extensions, two removable 12" X 20" diamond plated approach ramps, three cross tubes with lock rings, and a wheeled dolly. When the Atlas® Cycle Lift XLT kit is attached (this takes about three minutes), to the Atlas® Cycle Lift, the lift is transformed into the Atlas® Cycle Lift XLT. When the XLT kit is attached to the Atlas® Cycle Lift, the raised platform area is 93" X 48" and the approach ramps are 20" X 48 ".

  • Perfect for ATV's, motorcycles, golf carts, etc.
  • 93" table length
  • Side extensions included
  • Diamond plate surface
  • Vise included
  • Powder coated
  • Extended length standard
  • Air operated
  • Fits almost all choppers
  • Foot pedal included
  • Wheeled dolly included
  • 1 year structural, 1 year hydraulic warranty
Atlas® Cycle Lift XLT Specifications
Weight Capacity 1,000 LB.
Length w/ ramp 113" (9' 5")
Length w/o ramp 93" (7' 9")
Width 48" (4')
Full Rise 33" (2' 9")
Fully Lowered 7 1/4"
Removable approach ramp 20"
Length of Cut Out 19 1/2"
Cylinder 7" (internal size = 6")
Air Requirements 90 - 100 PSI / 5 CFM Delivery
Gauge of Steel 10 Gauge (.1345" / 3.42mm)


Black Jack 1000- $225.00 (Click image to enlarge)


 Black Jack 1000 Specifications
Maximum Weight Capacity 1,000 lbs.
Lifting Height with regular adapters 14"
Lifting Height with ATV adapters 16"
Width without adapter plate 5 1/2"
Width with adapter plate 11"
Length 16"

Atlas TD6MR- $2,395.00

The Atlas® TD6MR is a free standing 6,000 lb. capacity portable scissor lift. The Atlas® TD6MR is the perfect lift for body shops and wheel service specialists that need extra lifting height. This portable lift easily raises a 6,000 LB. car or truck to a comfortable working height. The unique platform design of the Atlas® TD6MR allows access to some areas on the underside of the car not easily accessible with other portable mid-rise lifts.

The dual power cylinders and the solid safety lock bar, with several different lock positions, make the Atlas® TD6MR one of the most popular mid-rise lifts sold in the USA and Canada.

Our Atlas® TD6MR has been thoroughly tested to meet Industry standards. The Atlas® TD6MR mid-rise lift is powered by a 110 volt power unit that is mounted on a movable cart. The power unit can be remotely located around the lift for maximum efficiency. This cart is also used to move the Atlas® TD6MR on a smooth surface. The lift can easily be rolled from an inside work bay to an outside concrete apron work area.

The Atlas® TD6MR is a complete mid-rise lift that includes one set (4) of truck adapters and another set of sliding car adapters. The arms can be adjusted to an infinite amount of positions in order to accommodate unique lifting points found on certain vehicles.

The best way to position any vehicle on a scissor lift (with horizontal cylinders) is to allow some space (2-6 inches) between the lifting surface of the lift and vehicle’s lifting points.

The large “foot print” of the Atlas® Pro TD6MR creates a steady platform for the raised vehicle. The Atlas® TD6MR has a lifting height of over 53” and remains rock solid at all safety lock positions.

  • Powder coated
  • 110V Motor (PLUG NOT INCLUDED)
  • Single point lock release
  • Commercial grade
  • Full 6,000 LB. capacity
  • Portable, easy to move
  • Two hydraulic cylinders
  • Safety locks at any work height
  • 7 locking positions
  • Truck adapters included
  • Free Standing
  • Separate motor stand included
  • 2 year structural, 2 year hydraulic limited warranty
  • Shipping Dimensions: 85" x 40" x 27"

Atlas® TD6MR Specifications

Capacity 6,000 LB.
Height-Lowered (Swing Arms) 5 ¾"
Height-Raised Maximum 53 ½" (4' 5 ½")
Width 39" (3' 3")
Length 82" (6' 10")
Small Truck Adapter 1 ½"
Large Truck Adapter 5 ¾"
Shipping Weight 1,050 LB.
Motor 110V
Oil Requirement 1.5 Gallons AW32/AW46
